Fire Hydrants and Standpipe Equipment

Hydrants, pressure-reducing valves, fire department connections and hose-coupling equipment used where a fixed fire suppression system meets the fire brigade

EQUIPMENT

What Is This Group Used For?

This group brings together the equipment where a fixed fire suppression system meets the fire brigade: above-ground hydrants, fire department connections (including Siamese connections), pressure-reducing angle and gate valves, and hose couplings and caps.

The dry-barrel hydrant (HYF) is the above-ground outlet point of the city main or a standpipe line; the barrel is kept dry against freeze risk, and water reaches the hydrant body only once the valve is opened. Fire department connections (A53, A53G, A55) and threaded Siamese connections are the connection points that let the fire brigade’s apparatus pump water into the system or draw water from it from outside the building. Pressure-reducing angle and gate valves (A201/A202, A203/A204) provide an adjustable limit on outlet pressure at the fire hose outlet on standpipe lines in tall buildings. Hose couplings and caps (K81D) are adapter and cap components that let different connection standards (NST, BSP, Storz, BS336) interface with one another.

This equipment is used at the fire-brigade connection and supply points of a water-based suppression system.

Selection Criteria

Approval scope: within this group, approval varies model to model — the HYF, A53 and A55 hold both UL and FM approval; the A201/A202, A203/A204 and A53G hold UL approval only; the K81D hose-coupling group has no separate approval line in the source. If your project's specification requires UL, FM or both, select the model against the approval column in the table.
Coupling standard: hose couplings are manufactured to different national/institutional standards — NST (American national standard), BSP, Storz and BS336 among them. Coupling selection should follow the hose-connection type used on the ground by the fire authority your project answers to.
Need for a pressure-reducing valve: in tall buildings, static pressure on a standpipe line can rise above the safe-use limit at the fire hose outlet; adjustable pressure-reducing valves such as the A201/A202 (angle type) or A203/A204 (straight-through gate type) are used in that case.
Body material: the hydrant body is cast iron; the fire department connection and pressure-reducing valves are cast brass/bronze — corrosion-resistant materials suited to outdoor and below-ground use.

Models We Supply

We supply the models below for your projects; for the full brand range see Viking fire protection products.

VIKING

HYF — Dry-barrel above-ground hydrant

Approvals: UL, FM
Max. working pressure: 17.2 bar (250 psi)
Material (body): Cast iron
Sizes: D = 76 mm – 213 mm
Connection: Flanged

Part numbers (20)

Diameter	Type	Part no.
D = 76 mm	PN16	HYF-025P
D = 91 mm	PN16	HYF-030P
D = 107 mm	PN16	HYF-035P
D = 122 mm	PN16	HYF-040P
D = 137 mm	PN16	HYF-045P
D = 152 mm	PN16	HYF-050P
D = 167 mm	PN16	HYF-055P
D = 183 mm	PN16	HYF-060P
D = 198 mm	PN16	HYF-065P
D = 213 mm	PN16	HYF-070P
D = 76 mm	ANSI #150	HYF-025A
D = 91 mm	ANSI #150	HYF-030A
D = 107 mm	ANSI #150	HYF-035A
D = 122 mm	ANSI #150	HYF-040A
D = 137 mm	ANSI #150	HYF-045A
D = 152 mm	ANSI #150	HYF-050A
D = 167 mm	ANSI #150	HYF-055A
D = 183 mm	ANSI #150	HYF-060A
D = 198 mm	ANSI #150	HYF-065A
D = 213 mm	ANSI #150	HYF-070A

Note: Available with mechanical-joint connections (HYM) — contact Viking.

VIKING

A201 & A202 — Pressure-reducing angle valve

Approvals: UL
Max. working pressure: 27,6 bar (400 psi)
Material (body): Bronze
Sizes: 2-1/2” (DN65) x 2-1/2” (DN65)
Connection: Threaded NPT x NST
Features: Adjustable outlet pressure · Angle pattern

Part numbers (2)

Connection size	Connection	Type	Part no.
2-1/2”F x 2-1/2”F	Dişli	NPT x NST	A201250250
2-1/2”F x 2-1/2”M	Dişli	NPT x NST	A202250250

¹ F = Female, M = Male

VIKING

A203 & A204 — Pressure-reducing gate valve

Approvals: UL
Max. working pressure: 27,6 bar (400 psi)
Material (body): Bronze
Sizes: 2-1/2” (DN65) x 2-1/2” (DN65)
Connection: Threaded NPT x NST
Features: Adjustable outlet pressure · Straight-through pattern

Part numbers (2)

Connection size	Connection	Type	Part no.
2-1/2”F x 2-1/2”F	Dişli	NPT x NST	A203250250
2-1/2”F x 2-1/2”M	Dişli	NPT x NST	A204250250

¹ F = Female, M = Male

VIKING

A53 — Straight-pattern fire department connection

Approvals: UL, FM
Max. working pressure: 20,7 bar (300 psi)
Material (body): Cast brass
Sizes: 2-1/2” (DN65) x 2-1/2” (DN65) & 3” (DN80) x 2-1/2” (DN60)
Connection: Threaded NPT x NST

Part numbers (2)

Connection size	Connection	Type	Part no.
2-1/2”F x 2-1/2”M	Dişli	NPT x NST	A53250250
3”F x 2-1/2”M	Dişli	NPT x NST	A53300250

¹ F = Female, M = Male

VIKING

A53G — Straight-pattern fire department connection (swivel thread)

Approvals: UL
Max. working pressure: 20,7 bar (300 psi)
Material (body): Cast brass
Sizes: 2-1/2” (DN65) x 2-1/2” (DN65) & 3” (DN80) x 2-1/2” (DN60)
Connection: Threaded NPT x NST
Features: Swivel-thread connection

Part numbers (1)

Connection size	Connection	Type	Part no.
2-1/2”F* x 2-1/2”M	Dişli	NPT x NST	A53G250250

¹ F = Female, M = Male · * Swivel thread

VIKING

A55 — Angle valve, fire department connection

Approvals: UL, FM
Max. working pressure: 20,7 bar (300 psi)
Material (body): Cast brass
Sizes: 1-1/2” (DN40) x 1-1/2” (DN40) & 2-1/2” (DN60) x 2-1/2” (DN60)
Connection: Threaded NPT x NST

Part numbers (1)

Connection size	Connection	Type	Part no.
1-1/2”F x 1-1/2”F	Dişli	NPT x NST	A55150150

¹ F = Female, M = Male

VIKING

K81D — Hose couplings and caps for K81D

Approvals: No approval listed — The source has no separate approvals line for this product group — the hose-coupling and cap parts are accessory items.
Connection: Threaded

Part numbers (12)

Size	Connection	Type	Description	Part no.
2-1/2”/DN65	Dişli	BSP	Hortum	HN25BSP
2-1/2”/DN65	Dişli	NPT	Hortum	HN25NPT
2-1/2”/DN65	Dişli	NST	Hortum	HN25NST
4”/DN100	Dişli	BSP	Basma ağzı	PN40BSP
4”/DN100	Dişli	NST	Basma ağzı	PN40NST
4-1/2”/DN115	Dişli	NST	Basma ağzı	PN45NST
2-1/2”/DN65	Dişli	F-NST	Storz - Dişi, Alüminyum	010145
2-1/2”/DN65	Dişli	F-NST	Storz - Kapak, Alüminyum	010112
2-1/2”/DN65	Dişli	F-NST	BS336 - Dişi, Alüminyum	010213
2-1/2”/DN65	Dişli	F-NST	BS336 - Dişi, Pirinç	010213B
2-1/2”/DN65	Dişli	F-NST	BS336 - Zincirli kapak, Alüminyum	010205
2-1/2”/DN65	Dişli	F-NST	BS336 - Zincirli kapak, Pirinç	101206B

VIKING

A95 / A96 / A105 / A106 — Threaded siamese connections

Approvals: UL, FM
Max. working pressure: 20,7 bar (300 psi)
Material (body): Cast brass
Sizes: 4” (DN100) x 2-1/2” (DN65)
Connection: Threaded NPT x NST

Part numbers (4)

Connection size	Connection	Type	Features	Part no.
4” x 2-1/2”	Dişli	NPT x NST	Düz tek klape	A95400250
4” x 2-1/2”	Dişli	NPT x NST	90° tek klape	A96400250
4” x 2-1/2”	Dişli	NPT x NST	Düz çift klape	A105400250
4” x 2-1/2”	Dişli	NPT x NST	90° çift klape	A106400250

Request a Quote for Your Project

Tell us the line diameter, coupling standard and approval scope you need; we'll work out the right model together.
